EcoFlow Home Backup Kit: Transfer SwitchManual Transfer Switch for Safe Home Backup Power
The EcoFlow Transfer Switch is a pre-wired manual transfer switch that safely connects your EcoFlow DELTA Pro, DELTA Pro 3, or DELTA Pro Ultra to your home’s critical circuits during a power outage. Choose the 6-circuit or 10-circuit model based on your compatible EcoFlow power station configuration.
Professional Installation Required. Installation must be performed by a licensed electrician in compliance with all applicable electrical codes. For indoor circuit breaker panels only.
Shipping Restriction. Cannot be shipped to Alaska, Hawaii, Puerto Rico, or other US outlying territories.
Choose Your Transfer Switch
| Model | Compatible EcoFlow Stations | Circuits | Voltage | NEMA Inlet |
|---|---|---|---|---|
| 306A1 125V / 60A / 6-Circuit |
Single DELTA Pro 3, DELTA Pro, or DELTA 3 Ultra Series | 6 circuits | 125V / 3,750W max | NEMA L5-30 |
| 306A 125/250V / 30A / 6-Circuit |
DELTA Pro 3 1 / DELTA Pro Ultra 1 / DELTA Pro 2 | 6 circuits | 125/250V / 3,7507,500W max | NEMA L14-30 |
| A510A 125/250V / 50A / 10-Circuit |
DELTA Pro 3 2 / DELTA Pro Ultra 2 | 10 circuits(1)2P 30A, (1)2P 20A, (6)1P 15A | 125/250V / 6,250W max | NEMA SS2-50 (CS6375) |
Key Features
- Completely Pre-WiredPlug & Play SetupFully pre-wired at the factory for easy installation by a licensed electrician; no field wiring of internal components needed
- Protect Up to 10 Critical Home CircuitsSelect the circuits that matter mostrefrigerator, garage door, lighting, outletsand keep them running during any outage
- cULus 1008 ListedCertified to UL 1008 safety standards; compatible with any UL-listed 1″ interchangeable circuit breaker; includes swing-up protective cover
- Clean, Silent Power AlternativeReplace noisy gas generators with your DELTA Pro ecosystem; safe for both indoor and outdoor use with zero fumes
- Wattmeters IncludedBuilt-in wattmeters let you monitor the load on each circuit to avoid overloading your power station
- 5-Year WarrantyMetal enclosure rated for indoor use; reconfigurable in the field for multiple double-pole circuits if needed
Specifications
| Specification | 306A1 | 306A | A510A |
|---|---|---|---|
| Voltage | 125V | 125V / 250V | 125V / 250V |
| Maximum Watts | 3,750W | 3,750W (125V) / 7,500W (250V) | 6,250W |
| Amps | 60A @ 125VAC | 30A @ 250VAC | 50A @ 125VAC |
| Circuits | 6 | 6 | 10(1)2P 30A, (1)2P 20A, (6)1P 15A |
| Power Inlet (NEMA) | NEMA L5-30 | NEMA L14-30 | NEMA SS2-50 (CS6375) |
| Frequency | 60 Hz | 60 Hz | 60 Hz |
| Enclosure | Metal / Indoor | Metal / Indoor | Metal / Indoor |
| Color | Gray | Gray | Gray |
| Certification | cULus 1008 Listed | cULus 1008 Listed | cULus 1008 Listed |
| Dimensions (WHD) | 7.7511.254.75 in | 7.7511.254.75 in | 11.7511.254.75 in |
| Shipping Weight | 10.92 lbs | 10.92 lbs | 16.05 lbs |
| Warranty | 5-Year | 5-Year | 5-Year |
