Pentair IntelliTouch Valve Module | 520285
The Pentair IntelliTouch Valve Module (520285) is an OEM replacement module designed for use with the Pentair IntelliTouch Pool & Spa Automation System. This valve module provides dedicated control outputs for automated valve actuators, enabling your IntelliTouch controller to operate multiple flow paths — such as pool/spa diverter valves, spa bypass, or heater bypass — with precision and scheduling logic.
What This Part Is For
This valve module is specifically made for the Pentair IntelliTouch Automation System. It interfaces with your IntelliTouch controller to expand or replace the valve control outputs that drive 24-volt actuators, helping automate water routing to features like spa, waterfall, or solar loops.
Features & Benefits
- OEM-compatible valve control module for IntelliTouch systems
- Provides reliable outputs for multiple valve actuators
- Enables automated sequencing of water routing functions
- Built to match Pentair standards for long-term performance
- Ideal when original valve module is failing or additional valve control is needed
Installation Notes
- Turn off panel power before servicing or connecting the module
- Mount the valve module in the designated IntelliTouch panel slot
- Connect actuator wiring to the appropriate terminals per your panel wiring diagram
- Power up and test valve operations through your IntelliTouch controller interface
Maintenance Tips
- Inspect actuator wiring periodically for corrosion or loose connections
- Check actuator response through the controller’s interface and test schedules
- Keep the equipment pad and panel area free of moisture and debris for reliable operation
